Sensor inalámbrico PIR con interruptor de encendido / apagado
$8.755 Neto
Detector de movimiento inalambrico,ndicador de alarma: LED rojo
Interruptor de encendido: encendido / apagado CE, ROHS, FCC
BI5*B311
Hay existencias
- Descripción
- Información adicional
- Ficha técnica / Descargas
Descripción
1. Instalación: montado en la pared;
2. Energía: batería 6F22 9V;
3. Distancia de detección: 12 m, ángulo de detección: 110 grados;
4. Distancia abierta: 100-150m;
5. Tener 2262 y 1527 IC Option;
| TD-IR202 Specifications | |
| Name | Wireless PIR Motion Sensor |
| Model | TD-IR202 |
| Power Supply | Battery |
| Battery Type | 6F22 Battery DC9V |
| Wireless frequency | 433MHz/315MHz |
| Wireless transmission range | 100-150 meters(Open area) |
| Coding chip and Resistance | 2262/1.5-4.7MΩ or EV1527/330KΩ |
| Detecting distence | 12m |
| Detecting angle | 110° |
| Alarm indicator | Red LED |
| Low battery indicator | Yellow LED |
| Power switch | ON/OFF |
| Antenna type | Telescopic antenna |
| Static current | ≤25μA |
| Alarm current | ≤15mA |
| Operation Temp. | -10°C to +50°C |
| Humidity | 5%–95% non-condensing |
| Dimension | 75mmx55mmx135mm |
| Weight | 150g |
| TD-IR202 Package List | |
| PIR Sensor | x1 |
| Bettery | x1 |
| Bracket | x1 |
| Screws | x2 |
| Plastic screw plug | x2 |
| User Manual | x1 |
Información adicional
| Condition |
|---|
